1. Electrical Specifications |
Type
|
Autotune
|
Frequency
Band |
851-869 MHz |
Number
of Channels |
4 |
Channel
Bandwidth |
25 KHz |
Minimum
Channel Spacing |
250 KHz |
Insertion
Loss (Max.) per Channel |
3.0dB |
Input
Return Loss (Min.) |
19dB
|
Output
Return Loss (Min.) |
8.5dB |
Isolation,
Tx-Tx (Min.) |
60dB |
Isolation,
Ant-Tx (Min.) |
50dB |
Input
Power/Channel Range |
75W |
Reflected
Power (Max.) Allowable from Ant. |
75W |
2. Mechanical Specifications |
Type
|
Autotune
|
Dimension(W*H*D)
|
277.1 * 282.8 * 246.0 |
Connectors
- Input |
N-Female |
Connectors
- Output |
N-Female |
3. Environmental Specifications |
Type
|
Autotune
|
Temperature Range
|
-20 ~ +55กษ |
|
|
|
|
