1. Electrical Specifications
Item
RX
TX
   Frequency Range
1885.625 ~ 1889.375MHz
1965.625 ~ 1969.375MHz
   Center Frequency (Fc)
1887.5MHz 1967.5MHz
   Bandwidth
3.75MHz
3.75MHz
   Insertion Loss (Max.)
1.5dB
1.0dB
   V.S.W.R. (Max.)
1.2 : 1 1.2 : 1
   Attenuation (Min.)
Fc 7.5MHz : 60dBc
Fc12.5MHz : 90dBc
Fc7.5MHz : 40dBc
   Isolation (Min.)
90dBc
   Impedance
50
   Handling Power (Max.)
20W
   Operating Temperature
+10 ~ +55

2. Mechanical Specifications

Item
RX
TX
   In / Out Connector
DIN - Female
   Size (W D H)
167 134 52
   Weight (Max.)
2Kg
