1. CDMA Specifications
Item
RX
TX
   Frequency Range
824.025 ~ 848.985MHz
869.025 ~ 893.985MHz
   Insertion Loss (Max.)
1.5dB
1.5dB
   Return Loss (Min.)
18dB
18dB
   Pass Band Ripple (Max.)
1.2dB
1.2dB
   Attenuation (Min.)
25dBc @ 821MHz
25dBc @ 851MHz
20dBc @ 866MHz
25dBc @ 896MHz
20dBc @ 896MHz
   Harmonics 2nd (Min.)
-
80dBc
   Coupling Port
-
30dB ¡¾ 1.0dB
   Isolation (Min.)
80dB
   Passive IM (Min.)
-
3rd : 140dBc
5th : 160dBc
(20W 2tone Input)
   Input Power
-
150W
   Impedance
50¥Ø
   Temperature / Humidity
-30¡É ~ + 70¡É / 5 ~ 90%
   Connector Type
TX : N-Female , RX : SMA-Female

2. WCDMA Specifications

Item
RX
TX
   Frequency Range
1940.88 ~ 1959.32MHz
2130.88 ~ 2149.32MHz
   Insertion Loss (Max.)
1.5dB
1.2dB
   Return Loss (Min.)
18dB
18dB
   Pass Band Ripple (Max.)
1.0dB
1.0dB
   Attenuation (Min.)
10dB @1937.5MHz
10dB @1962.5MHz
10dB @2127.5MHz
10dB @2152.5MHz
60dBc @ 9KHz ~ 800MHz
80dBc @ 800MHz ~ 1870MHz
80dBc @ 2300MHz ~ 2700MHz
40dBc @ 2700MHz ~ 12.75MHz
   Harmonics 2nd (Min.)
-
80dBc
   Coupling Port(Ãâ·Â±âÁØ)
-
40dB ¡¾ 1.0dB
   Coupler Directivity(Min.)
- 15dB
   Isolation (Min.)
110dB
   Passive IM(Min.)
-
3rd : 140dBc
5th : 160dBc
(20W 2tone Input)
   Input Power
-
150W
   Impedance
50¥Ø
   Temperature / Humidity
-30¡É ~ + 70¡É / 5 ~ 90%
   Connector Type
TX : N-Female , RX : SMA-Female
