Item
Specifications
   Frequency Range
7125~ 7750 MHz Fc=7437.5MHz
   Insertion Loss (Max.)
1.0dB
  Ripple (Max.)
  Fc กพ 312.5MHz
0.4dB
  In Band (18MHz)
0.3dB
   Retrun Loss (min)
17.7dB
   Attenuation(Min.)
  Fc กพ 800MHz
45dBc

  DC~6250MHz
8650MHz~14GHz

50dBc

  14GHz~16GHz

70dBc
   In Port
SMA-Female
   Out Port
N-Female
   Weight (Max.)
200g
