Item
Specifications
16GHz Cavity Filter
17.03GHz Cavity Filter
   Frequency Range
15.85 ~ 16.15GHz
16.9 ~ 17.16GHz
   Insertion Loss (Max.)
2.0dB
   Ripple (Max.)
1.0dB
   Rejection (Min.)
60dBc @ 15GHz 60dBc @ 16GHz
60dBc @ 17GHz 60dBc @ 18GHz
   Retrun Loss (Min)
14dB
