Item |
Specifications |
| Frequency Range |
470 ~ 862MHz |
| Insertion Loss (Max.) |
Fc |
0.9dB |
| Fc กพ 4MHz |
1.4dB |
| Ripple (Max.) |
0.8dB |
| Return Loss (Min.) |
25dB |
| Attenuation (Min.) |
|
20dB |
| Group Delay (Max.) |
300ns |
| Power Rating (Ave.) |
50W |
| In/Out Port |
N - Female |
| Temperature Range |
-10กษ ~ +50กษ |
| Size (W x D x H) (mm) |
138.5 x 95.0 x 35.0 |
| Weight (Max.) |
1Kg |
|
|
|
|
