Item
2CH
3CH, 4CH
5CH~8CH
   Insertion loss(Max.)
-
- -
         fc
0.3dB
0.5dB
0.5dB
         fc2.79
0.5dB
0.7dB
0.9dB
   VSWR(Max.) 1.2 : 1 1.2 : 1 1.3 : 1
   Isolation(Min.) 25dB
   Group Delay(Max.) 300ns
   In/Out Connector N-J or WX-20D
   Operating Temp. -10 ~+45
