| Item |
Specifications |
| Frequency Range |
470 ~ 862 MHz |
| Insertion
loss(Max.) |
Fc |
NB |
1.0dB |
| WB |
0.2dB |
| Fc ¡¾ 4MHz |
NB |
1.5dB |
| WB |
0.25dB |
| Ripple (Max.) |
NB |
0.8dB |
| WB |
0.15dB |
| Return Loss (Min.) |
NB |
30dB |
| WB |
20dB |
| Isolation (Min.) |
NB¡êWB |
30dB |
| Power Rating (Ave.) |
NB |
50W |
| WB |
200W |
| In/Out Port |
N - Female |
| Temperature Range |
-10¡É ~ +50¡É |
| Size (W x D x H) (mm) |
251.7 x 180.0 x 43.0 |
| Weight (Max.) |
2Kg |
| ¡Ø NOTE : NB-> Narrow Band, WB-> Wide Band |
|
|
|
|
