Item
|
Specifications |
16GHz Cavity Filter |
17.03GHz Cavity Filter |
Frequency Range |
15.85 ~ 16.15GHz
|
16.9 ~ 17.16GHz |
Insertion Loss (Max.)
|
2.0dB |
Ripple (Max.) |
1.0dB |
Rejection (Min.) |
60dBc @ 15GHz |
60dBc @ 16GHz |
| 60dBc @ 17GHz |
60dBc @ 18GHz |
Retrun Loss (Min) |
14dB |
|
|
|
|
