* [8IH-500/T2000]
: : A RF signal filter that filters out every frequency
except those within the band from 500 MHz to 2 GHz.
* [8IH-2000/T6000]
: A RF signal filter that filters out every frequency
except those within the band from 2 GHz to 6 GHz. |
Item
|
8IH-500/T2000 |
8IH-2000/T6000 |
Cutoff
Frequency |
500MHz
|
2000MHz |
Upper Passband Limit
|
2000MHz |
6000MHz |
Insertion Loss (Max.) |
1.2dB |
1.5dB |
Rejections
(Min.) |
55dB@ ¡Â 420MHz |
55dB@ ¡Â 1670MHz |
VSWR(Max.) |
1.5:1 |
1.5:1 |
|
|
|
|
